JCB 175

JCB - Mini cranes

Weight 3.093 t
Standard tyres 10x16.5-8 PR
Bucket width 1.676 m
Bucket capacity 0.4 m³
Driver protection KbR
Steering mode AL
Transport length 3.49 m
Transport width 1.52 m
Transport height 1.98 m
Travel speed 12 km/h
Max. discharge height 2.26 m
Lifting force 21 kN
Engine manuf. Kohler
Engine type KDI 1903 TCR
Engine power 42 kW
Engine power 56 HP
Dimension lxwxh 598.3x530x726 mm
Displacement 1.86 l
Revolutions at max torque 1500
Max. torque 225 Nm
No. of cylinders 3
Cylinder bore x stroke 88x102 mm
Weight 233 kg
Emission level IIIB/T4f
