HYUNDAI 205
HYUNDAI 205
HYUNDAI - Mini cranes
| Weight | 3.31 t |
|---|---|
| Standard tyres | 10x16.5-8 PR |
| Bucket width | 1.83 m |
| Bucket capacity | 0.44 m³ |
| Driver protection | KbR |
| Steering mode | AL |
| Transport length | 3.61 m |
| Transport width | 1.6 m |
| Transport height | 1.98 m |
| Travel speed | 12 km/h |
| Max. discharge height | 2.26 m |
| Engine manuf. | Kohler |
| Engine type | KDI 2504 TCR |
| Engine power | 46 kW |
| Dimension lxwxh | 704.3x523.2x719.5 mm |
| Displacement | 2.482 l |
| Max. torque | 300/1500 Nm |
| No. of cylinders | 4 |
| Cylinder bore x stroke | 88x102 mm |
| Weight | 267 kg |
